CXHN Series

．Use HNMX double-sided inserts with 12 cutting edges.

．Sharp cutting edge design for low depth-of-cut face milling.

．50 ~ 100mm cutter diameter, max. 3.5mm depth of cut.

．使用 HNMX 雙面銑刀片 , 12 個可用切削角

．鋒利切削刃設計適用於淺切面銑加工

．50 ~ 100mm 刀盤直徑 , 最大切削深度可達 3.5mm

CXSN Series

．Use SNMX or ONMX double-sided inserts with 8 or 16 cutting edges.

．2 type inserts can fit in same cutter for multiple applications.

．50 ~ 202.9mm cutter diameter, max. 6mm depth of cut.

．使用SNMX或ONMX雙面銑刀片, 8或16個可用切削角

．兩種刀片可鎖附在相同刀盤上，可應用於不同的深淺加工

．50 ~ 202.9mm 刀盤直徑 , 最大切削深度可達 6mm

CAOF Series

．Use OFMT inserts with 8 cutting edges.        

．Cost effective for low depth-of-cut face milling.        

．50 ~ 100mm cutter diameter, max. 2.8mm depth of cut.

．使用 OFMT 銑刀片 , 8 個可用切削角

．經濟實惠的較淺面銑加工        

．50 ~ 100mm 刀盤直徑 , 最大切削深度可達 2.8mm

CASE Series

．Use SEKT or SEKW inserts with 4 cutting edges.        

．Cost effective for wide range face milling applications.

．50 ~ 100mm cutter diameter, max. 5.5mm depth of cut.

．使用 SEKT 或 SEKW 銑刀片 , 4 個可用切削角

．經濟實惠的不同切深面銑應用        

．50 ~ 100mm 刀盤直徑 , 最大切削深度可達 5.5mm

CASX Series

．Use SEMT inserts with 4 cutting edges.        

．Cost effective for wide range face milling applications.

．50 ~ 315mm cutter diameter, max. 5.5mm depth of cut.

．使用 SEMT 銑刀片 , 4 個可用切削角

．經濟實惠的不同切深面銑應用        

．50 ~ 315mm 刀盤直徑 , 最大切削深度可達 5.5mm

CR24 Series

．Use W245-12T3 inserts with 4 cutting edges.        

．High performance face milling tools for general purpose.

．50 ~ 315mm cutter diameter, max. 5.5mm depth of cut.

．使用 SEMT 銑刀片 , 4 個可用切削角

．經濟實惠的不同切深面銑應用        

．50 ~ 315mm 刀盤直徑 , 最大切削深度可達 5.5mm
